Product description
1. High Quality
- Adopt gradeability improving style electronic hydraulic transmission, compare with other models: efficiency 5% improved, climbing torque 8% increased, noise 3~5dB reduced, thermal equilibrium temperature 8-10°decreased；
- The super large capacity aluminum tube belt radiator and optimized heat dissipation channel further improve the heat dissipation capacity of the vehicle；
- Load sensing priority steering hydraulic system is adopted to reduce pressure loss of the hydraulic system, save energy and improve operation comfort.
2. High Security
- Introducing advanced technology from Germany, the unique single chain has greatly enhanced the front view while working.
- All car LED lights, high brightness, long life, energy saving, and environmental protection.
3. High Comfort
- The new suspension system, adjustable seat, allowing the driver to feel more comfortable and reducing fatigue during long operations;
- The combined color instrument has strong human-machine interaction and timely and accurate feedback on the running state of vehicles.
- Spacious control space, comfortable seats, enjoy the pleasure of riding.
4. Rich Options
ISUZU engine, high exhaust device, air prefilter, fireproof cap, solid tire, two-stage free lift mast, three-stage free lift mast, widening fork frame, fork sleeve, side shifter, paper roll clamp, bale clamp, carton clamp, block clamp, rotators, drum clamp, push-pull, etc.
Main Parameters
| Model | UNIT | JGM5120 | ||
| Specifications | Power Unit | Diesel | ||
| Operator Type | Driver/seat | |||
| Transimission Bo× Type | Electronic hydraulic transmission | |||
| Rated Capacity | kg | 12000 | ||
| Load Center | mm | 600 | ||
| Ma×.Lifting Height | mm | 3000 | ||
| Tire Type | Pneumatic Tyre | |||
| Tire Number | Front | 4 | ||
| Rear | 2 | |||
| Tire Size | Front | 10.00×20-14PR | ||
| Rear | 10.00×20-14PR | |||
| Performance | Lifting Speed | Loaded | mm/s | 380 |
| Unloaded | 410 | |||
| Lowering Speed | Loaded | mm/s | 450 | |
| Unloaded | 400 | |||
| Travelling Speed | Loaded | km/h | 26 | |
| Unloaded | 30 | |||
| Ma×.Gradeability (Loaded) | % | 20 | ||
| Ma×.Drawbar Pull (Loaded) | kg | 6000 | ||
| Mast Tilting Angle (Fwd/Bwd) | deg | 6月12日 | ||
| Free Lifting Height | mm | 180 | ||
| Turning Radius | mm | 4000 | ||
| Dimensions | Overall Length (with fork) | mm | 5600 | |
| Overall Width | mm | 2160 | ||
| Overhead Guard Height | mm | 2560 | ||
| Fork Size (L×W×T) | mm | 1220×180×80 | ||
| Mast Height (Fork lowered) | mm | 2850 | ||
| Battery (Voltage/Capacity) | V/Ah | 2×12/80 | ||
| Truck Weight | kg | 13000 | ||
| Fuel Tank Capacity | L | 143 | ||
| Engine | Brand | ISUZU | ||
| Model | 6BG1 | |||
| Rated Power | kw/rpm | 82.3/2000 | ||
| Rated torque | n-m/rpm | 418/1500 | ||
| Number Of Cylinder | 6 | |||
| Displacement | 6.49 | |||
