1. Engine
Electric-controlled direct jet engine updated based on 4-cylinder Yuchai BOSCH power
engine that has been verified by the market and meets China's latest emission standards. The engine features low
fuel consumption, high combustion efficiency, and outstanding durability.
2. Reliable chassis
Reasonable structure design improves the durability and stability of working
mechanisms. The plate thickness at the key position is enhanced and the structural components are robust and
durable.
3. Hydraulic system
1) High-quality imported hydraulic components;
2) The multi-way valve has greater strength and faster speed.
3) The combined action time of rotating and boom lifting is shorter and the
operation efficiency is higher.
4) Hydraulic locks are installed on the bulldozer blade and the outrigger cylinder
to prevent internal leakage of the cylinder.
4. Safe operating system
1) Parking mode, four wheels locked, the whole machine is more stable during
operation.
2) Electronic automatic parking can realize automatically park at the same time after
the engine is turned off, thus ensuring parking safety.
5. Cab
1) The shift handle is placed in front, which is convenient to operate.
2) The instrument is installed on the side, which can comprehensively monitor the
working state of the whole machine.
3) Humanized design of the cab, beautiful and generous, broad vision, exquisite
interior decoration.
4) Direction machine swing adjustment range is large, the whole machine comes standard
with air conditioning, and the driver is more comfortable operating.
6. Power system
1) The engine is using T3 engine, and the whole engine has strong power performance.
2) The high and low temperature areas of the engine are separated by clapboards,
and the intake air of the engine is in the low temperature area so that the heat dissipation effect of the whole
engine is better.
| Items |
Parameters |
| Operating weight (kg) |
7240 |
| Rated load (kg) |
700 |
| Maximum width of grab (mm) |
1360 |
| Rated power/speed (kW/rpm) |
55/2200 |
| Displacement (ml) |
3621 |
| Max torque (N.M) |
315 |
| Gradeability( °) |
30 |
| Slewing speed (r/min) |
0～11 |
| Travel speed (km/h) |
0～30 |
| Overall dimension (mm) |
6485×2140×2910 |
| Min. ground clearance (mm) |
340 |
| Tail swing radius (mm) |
1820 |
| Wheelbase (mm) |
2380 |
| Wheel tread (mm) |
1670 |
| Max lifting height (mm) |
7600 |
| Max hoisting depth (mm) |
4120 |
| Max hoisting radius (mm) |
7190 |
| Max dumping height (mm) |
5080 |
| Max ground hoisting distance (mm) |
7010 |
| Max bulldozing depth (mm) |
220 |
| Max bulldozing height (mm) |
560 |
| Boom length (mm) |
3700 |
| Arm length （mm） |
2000 |
| Dozer blade width (mm) |
2200 |
| Tire |
8.25-16 |
| Fuel tank capacity (L) |
120 |
| Hydraulic tank capacity (L) |
140 |
| The structure and parameters are subject to change without prior notice due to
technical progress. If the sample product is different from the actual product in some way, the actual
product shall prevail.
|
Note: Specifications are subject to changes by the manufacturer without prior notice.
