Product description
OPERATOR-ORIENTED DESIGN
The controller is easy and comfortable to operate
Vibration-absorbing Type Cabin
The cabin is installed on hydraulic elastic support to realize vibration absorption and resonance reduction
Full View Cabin
The full-view cabin has widened front window and no column at the back corner, which enables a nearly full view.
The frontal wheels are always in view of the
SAFETY-FIRST DESIGN
The advanced mechanism combination realizes high-level safety during of operation
OPERATING COST REDUCED
With integrated check spots, the components are very durable to operate the maintenance cost is largely reduced engine Cover Back Tipping Clear Pipelines Layout Detachable cabin meets the demand of different working environments Oil tank is turnable for easy daily maintenance
ENHANCED DURABILITY
The constant quality improvement enhances the machine
durability and enables long-time continuous work!
High-Efficient Drive System
1. Reliable engine
Engines of a famous domestic brand are used to guarantee great
power, big torque reserve, low oil consumption, low noise, and
reliable performance.
2. Durable transmission & torque converter. Fixed shaft power shift transmission has a compact structure and
high transmission efficiency
3. Axle specialized 20 driving axles with big modules and high reliability. It can stand the test of years of high-duty operation in mines.
Boom- Reliable & Excellent Performance
The dumping height reaches 2630mm (the dumping height of extended can reach 2850mm or 3100mm), this can be equal to a 3-ton wheel loader. The function of material auto leveling improves working efficiency. The digging force reaches 65kN, which is 16% bigger than the other counterparts.
Strong Chassis
The section shows truck-type frame is thickened and strengthened to resist the torque force and improve durability. The central pin interval relatively wide also to improve the torque force resistance performance
3. EASY AND COMFORTABLE OPERATION
Operating a K Series wheel loader is unique to every operator. Operators can fully customize their work environment and operating preferences to fit their individual needs.
Spacious Cab with Excellent View
Spacious cab designed with ergonomics approach boasts low noise and excellent view, are shaped front window, large rear window, and side windows offer a wide view in all directions.
Centralized Monitoring Panel
Centralized monitoring panel designed with simplicity of ergonomics that shows working conditions and warning lights at a glance.
Easy Controlled Rocker Switches
All the switches are arranged in concentrated and combined ways, which makes it easy to operate.
Standard Large Capacity Air Conditioning
Large capacity, air circulation, and defrost system make the space comfortable for operators.
Excellent Air Circulation System
Excellent air conditioning and circulation system provide operators with the more comfortable working environment.
Suspension Seat
It can be adjusted to the position optimized for the driver's weight and size reducing the operator's fatigue.
Rear Wiper (Option)
In case of rain, a lot of dust in the work environment, improves rear visibility.
Large Side Mirror
A large side mirror ensures the operator's driving safety.
Air Purification Filter
It effectively filters dust out of the cab to keep the air clean and fresh.
Rear View Camera (Option)
Optional rearview camera helps you keep an extra eye on the job site.
Headlight and Turn Signal
Lights are beautifully and durably designed.
Customized Operation with Joystick Control (Option)
4. SERVICEABILITY
The JinGong JGM7 Series is the ideal equipment for easy maintenance and service.
Key-Locking Fuel Cap
The location of fuel cap increased accessibility and key locking function is applied for the prevention of vandalism.
Oil Sight Gauge
The hydraulic oil check sight gauge is installed on the side of the hydraulic tank for the convenience of maintenance check from ground level.
Quickly Changeable Brake Disc
The brake discs can be replaced quickly and easily without removing the tires, which saves maintenance time.
Non-Slip Platform
Non-slip platform and steps ensure operator's safety.
Easy Access to Engine Compartment
Engine hood with two side wing flap opened door provides access for maintenance to easily replace engine components and perform daily maintenance.
Performance parameters
| Item | JGM718K | |
| Buctket capacity (m3) | 1.0 | |
| Rated load (㎏) | 1800 | |
| Operating weight (㎏) | 5800 |
|
| Max. dumping height (mm) | 2650 | |
| Max. dumping distance (mm) | 980 | |
| Wheelbase (mm) | 2350 | |
| Wheel track (mm) | 1450 | |
| Ground clearance (mm) | 230 | |
| Overall length (mm) | 5630 | |
| Overall height (mm) | 2850 | |
| Bucket width (mm) | 2000 | |
| Dumping angle (°) | 43 | |
| Max. breakout force (kN) | ≥45.4 | |
| Max. traction force (kN) | ≥50 | |
| Min. turning radius, at bucket transporting position (㎜) | 5190 | |
| Turning radius(at outside of tire) (㎜) | 4800 | |
| Total cycle time (S) | ≤6.5 | |
| Engine | Model | YTO YT4B3-G98Q(Tier II） |
| Rated power (KW) | 60 | |
| Rated speed (r/min) | 2200 | |
| Travel speed (Km/h) | F1/R1 | 0-9 |
| F2/R2 | 0-23 | |
Note: Specifications are subject to changes by the manufacturer without prior notice.
