1. Special backhoe loader chassis, compact structure and reasonable layout;
2. Equipped with a fully enclosed cab with a wide field of vision, the whole machine has a beautiful
appearance, and the leading design of the all-round humanized control system makes the whole machine operation
more reasonable and comfortable;
3. The engine adopts the Yuchai engine, which is environmentally friendly and powerful, which greatly
improves the fuel economy and work efficiency, and greatly reduces the customer's use cost; a variety of
domestic and foreign well-known brands engines can be selected.
4. The original SEM professional backhoe loader transmission system is adopted, and the hydraulic system adopts
domestic well-known brands to ensure the stability of product quality, and the performance of the whole machine
reaches the international advanced level;
5. Excellent excavation and loading performance brings value-added returns to customers;
6. The original SEM drive axle ensures the traction performance of the whole machine and the safety performance
of the whole vehicle; the design of the swing steering axle, the steering angle and the swing angle are large so
that the whole vehicle has better passability. Service and parking brakes adopt air over oil calliper brake,
external type, elf-regulation, and self-balances;
7. Two-wheel and four-wheel drive can meet the needs of customers;
Model |
|
JGM665E |
Operating weight(T) |
kg |
8200 |
Transport Dimensions (L*W*H ) |
mm
|
5920×2250×3770 |
Wheelbase |
mm |
2200 |
Min. Ground Clearance |
mm |
300 |
Bucket Capacity (Excavating bucket) |
m3 |
1.0 |
Breakout Force |
KN |
38 |
Loading Lifting Capacity (Excavating bucket) |
KG |
2500 |
Bucket Dumping Height |
mm |
2742 |
Bucket Dumping Distance |
mm |
925 |
Digging Depth |
mm |
52 |
Backhoe Capacity |
m3 |
0.3 |
Max. Digging Depth |
mm |
4082/4500 |
Swing Angle of Excavator Grab |
˚ |
190 |
Max. Traction |
KN |
39 |
Engine |
|
Model |
|
YC4A105Z-T20 |
Type |
|
In-Line Direct injection Four-Stroke and Injection Combustion
Chamber
|
Rated Power |
KW |
75 |
Cylinder-Inside Diameter*Stroke |
|
4-102×120
|
Min. Fuel Consumption |
|
≤242g/km.h |
Rated Speed |
rpm |
2200r/min |
Displacement |
L |
4.4 |
Consumption |
|
Euro 2 |
Max Torque |
|
≥410N.M |
Transmission System |
|
|
Model
|
|
YJ280 |
Type |
|
Single-stage Three Elements |
Max. Efficiency |
%
|
84.4 |
Inlet Pressure |
Mpa |
0.5 |
Outlet Pressure |
Mpa |
1.1—1.3 |
Cooling Method |
|
Oil-cooling Pressure Circulation |
Gearbox |
|
|
Type |
|
Fixed Shaft Power Transmission |
Oil Pressure of Clutch |
|
1373Kpa—1569 Kpa |
Gears |
|
Two Gears Ahead, Two Gears Astern |
Max. speed |
Km/h |
28
|
Hydraulic system |
|
|
Digging Power of Excavator Grab |
KN |
46.5 |
Digging Power of Dipper |
KN |
31
|
Bucket Lifting Time |
S
|
6.8 |
Bucket Lowering Time |
S
|
3.1
|
Bucket Discharge Time |
S
|
2.0
|
Tyre |
|
Model |
|
14-17.5/19.5L-24 |
Pressure of Front wheel |
Mpa |
0.55
|
Pressure of Back Wheel |
Mpa |
0.23
|
Brake system |
|
Service Brake |
|
Air Over Oil Caliper Brake, External Type,
elf-regulation, Self-balance |
Emergency Brake |
|
Operation Power Implementing brake, Manual
Operation Power Terminating Brake |
Steering System |
|
Model of Steering Device |
|
BZZ5-250 |
Steering Angle |
˚ |
±36 |
Min. turning radius |
mm |
6581 |
Pressure of the system |
Mpa |
12 |
Axle |
|
Manufacturer |
|
Feicheng Axle Factory |
Main Transmission Type |
|
Double Reduction |
Final Reducer |
|
Single Stage Final Reducer |
Rated Loader of Axle |
|
8/18.5t |
Note: Specifications are subject to changes by the manufacturer without prior notice.
